CHL6000 with 48” lifting height
CHL4000 with 48” lifting height
CHL4000 with 48” lifting height
| Model | CHL 1500 | CHL 3000 | CHL 4500 | CHL 6000 | CHL 9000 | |
|---|---|---|---|---|---|---|
| Lifting Capacity (lb) | 1500 | 3000 | 4500 | 6000 | 9000 | |
| Maximum Beam | 60" | 70" | 110" | 122" | 122" | |
| Outside width | 72" | 72" | 108" | 108" | 108" | |
| Lifting Height | 48"-60" | 48"-60" | 48"-60" | 48"-60" | 48"-60" | |
| Bunk Length | 6' | 10' | 12' | 14' | 16' | |
| Min. water ht. | 20" | 20" | 25" | 25" | 28" | |
| Max. water ht. | 96" | 96" | 120" | 120" | 120" | |
| Shipping wt. | 300lb | 300lb | 565lb | 625lb | 900lb | |
| # hyd cylinders | 1 | 1 | 2 | 2 | 4 | |
| Lifting time (appr) | 20 sec. | 25 sec. | 25 sec. | 25 sec. | 35 sec. |
Canadian Manufacturer
Local representation
Fully customizable manufacturer for those ‘difficult locations’
3 week delivery and Installation
Largest Cylinder per weight class in Industry.
PVC bunks
Model ranges from 1500lb-9000lb
Adjustable lifting heights 48-60”
Heavy Duty marine grade aluminum extrusions
12V Hydraulic control box
12V HD marine battery INCLUDED
AC Charger INCLUDED
2 Hand held remotes INCLUDED
Installation INCLUDED
Strongest Frame in industry
10 Year Structural Warranty
2 year standard warranty
Environmentally friendly biodegradable hydraulic fluid
Marine grade cylinders with Stainless Steel shafts
10 Watt Solar panel
Control Box shelve(s)
Motor Stops
Vertical Guide Posts
Leg extensions for deep water
Hard Wired Wall Switch
